FEATURE
- Ultra-high quality compact chorus pedal for guitarists and keyboardists
- High- and Low-cut filters for shaping tonality of the chorus
- Offers Effect Level, Rate, Depth and Filter knobs for complete control
- Mono input and Stereo outputs for connection to dual amps or for studio use
- Produces a range of chorusing effects, from subtle to extreme
- BOSS five-year warranty
SPECIFICATION
Nominal Input Level
-20 dBu
Input Impedance
1 M ohms
Nominal Output Level
-20 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Bypass
Buffered bypass
Controls
HIGH FILTER/LOW FILTER knob
DEPTH knob
RATE knob
E.LEVEL knob
Pedal switch
Indicator
CHECK indicator (Used for indication of check battery)
Connectors
INPUT jack: 1/4-inch phone type
OUTPUT A/B jack: 1/4-inch phone type
DC IN jack
Power Supply
Carbon-zinc battery (9 V, 6F22) or Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)
Current Draw
25 mA
Expected battery life under continuous use
Carbon: Approx. 11.5 hours
Alkaline: Approx. 25.5 hours
*These figures will vary depending on the actual conditions of use.
Accessories
Owner’s manual
Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
Carbon-zinc battery (9 V, 6F22)
Options (sold separately)
AC adaptor (PSA series)
SIZE AND WEIGHT
Width
73 mm
2-7/8 inches
Depth
129 mm
5-1/8 inches
Height
59 mm
2-3/8 inches
Weight
410 g
15 oz
