R-44

A COMPACT, SOLID STATE, 4-CHANNEL FIELD RECORDER

The R-44 is a compact, four channel, solid-state field recorder that uses SD or large capacity SDHC cards as the storage media enabling quiet and reliable recording for a variety of professional audio needs. Capture up to 4 channels of uncompressed audio with selectable bit depths (16-bit or 24-bit) and sampling frequencies (44.1kHz/48kHz/88.2kHz/96kHz/192kHz). Onboard effects include limiter, low cut filter, 3-band EQ, 6-band GEQ, Enhancer, and DeEsser. The R-44 is a part of our series of audio field recorders.

Description

FEATURE

  • 24-bit/192kHz WAV recording
  • Solid-state recording to SD & SDHC cards
  • 4 hours of recording time with NiMH batteries
  • Dual gain and sensitivity control
  • Record 8-channels by linking two units

The R-4 Pro is a part of our series of audio field recorders. Compare Audio Field Recorders.

Pro quality four channels recordings to large capacity SDHC cards.

The R-44 is designed for professional use within a very conveniently sized package. Capture up to 4 channels of uncompressed audio with selectable bit depths (16-bit or 24-bit) and sampling frequencies(44.1kHz/48kHz/88.2kHz/96kHz). R-44 employs SD cards or large capacity SDHC cards as the recording media. No moving parts enables the most silent and reliable operation possible.

Built-in stereo microphones and monitor speakers

Although the R-44 is compact, all the necessary functions are included. Built-in high quality microphones and speakers make recording and monitoring without external devices possible.

Built-in Effects

3-Band EQ: 3-band parametric EQ ; allows precise equalization with high/low shelving and peaking

6-Band Graphic EQ: 6 point frequency band equalization; ideal for recording

Noise Gate: Minimizes noise during low audio levels, cuts low frequency noise

Enhancer: Cleary defines and enhances sound; good for dialogue

Comp & DeEsser: Cuts hissing, smoothens the sound, makes audio level uniform

MS Mic Mixing: Generates stereo mix with specified spread from inputs of Mid-Side Microphones

* Effects can be applied on both input and output. * Effects are not available while sample rate is set to 192kHz.

Built-in limiter, low-cut filter and studio class effects

An on-board limiter helps suppress sudden peaks in sound from an input source. A low-cut filter is included to help prevent things like wind noise or mic handling noise. Studio class effects such as 3-Band EQ, 6-Band GEQ, Enhancer or DeEsser can be used as tools to greatly improve audio quality. Effects can be applied while recording or simply for monitoring/playback.

Pre-Record function ensures you never miss that important moment again

The Pre-Record function buffers input signals for a user-definable amount of time. When the REC button is pressed, the material from the previous few seconds (selectable) is included. This also helps reduce sound bites at the beginning of a recording by not having to start the recorder too early.

Combo type analog jacks and digital output enables connection with a variety of devices

The combo input jacks (4) supports the connection of both XLR and 1/4 inch plugs. XLR inputs are equipped with phantom power. Eleven steps of input sensitivity enable the connection of various devices with a variety of inputs levels from microphones to musical instruments. High quality analog circuitry in the preamp ensures superior recording results

High-contrast Organic LED display and operation-oriented user interface

The high contrast, high response organic LED screen, viewable from wide angles ensures fluid operation in field recording situations. The high response of level meters makes precise level adjustments possible. All the necessary switches and knobs are located on the top and front panels. Self-lit buttons on all the key controls enable clear-cut recording operations.

Capture eight channels by linking two units

The Control Sync terminal enables synchronized operation of 2 units. Control the second unit from the master by simply connecting two with a stereo mini cable. The master unit can remotely control REC standby, REC start and REC stop of the slave unit. This function enables 8-channel recording in a compact space and at an affordable price.

Link to computer via high speed USB

The R-44 storage can be mounted on computers with a simple USB 2.0 connection. It is seen as an USB storage device on any computer. You can copy data back and forth with a simple drag & drop operation.

Four hours of recording with four AA batteries

The R-44 can be operated with 3 types of power: AC adapter and AA batteries. Four hours* of operation is possible with NiMH or alkaline batteries.
* at 16-bit/44.1kHz stereo. No phantom power and pre-record disabled.

RECORDER SECTION

Channels

4


Data Type

Format : WAV/BWF


Sampling Bit Rate

16/24-bit


Sampling Frequency

44.1kHz/48kHz/88.2kHz/96kHz/192kHz (Limited to Stereo x 1 at 192kHz) * 16 or 24-bit sampling rate can be selected with any frequency


Recording Media

SDHC / SD memory card (compatible with 64 MB – 32 GB)


Recording Time using 8 GB SDHC card

16 bit/44.1kHz : 755 minutes (Stereo), 377 minutes (4ch)
16 bit/48kHz : 694 minutes (Stereo), 347 minutes (4ch)
24 bit/48kHz : 462 minutes (Stereo), 231 minutes (4ch)
24 bit/96kHz : 231 minutes (Stereo), 115 minutes (4ch)
24 bit/192kHz : 115 minutes (Stereo)

* Recording times are approximate. Actual results may vary somewhat.
* If more than one recorded file exists, the total recordable time will be less than listed.


INPUT AND OUTPUT

Analog Input

Ch 1 – 4 : XLR/TRS Combo type, XLR type (phantom powered)


Analog Output

Ch 1 – 4 : XLR/TRS Combo type, XLR type (phantom powered)


Digital In/Out

RCA Pin type (IEC 60958-3)


Input Impedance

XLR: 4k ohms or greater (balanced), TRS: 6k ohms or greater (balanced)


Nominal Input Level

11 steps : -56, -50, -44, -38, -32, -26, -20, -14, -8, -2, +4 (Input Level Knob : Center)


Maximum Input

+24 dBu (Input Sens Knob: +4 dBu)


Output Impedance

Line Output : 600 ohms


Recommended Load Impedance

Line : 4k ohms or greater


Output Level

Line Output : -20 dBu (fixed)


Total Harmonic Distortion + Noise

Line Output : 0.02 % (Input Sens : +4 dBu)


Noise Level

Line Output : -100 dBu (Input Sens : +4 dBu, Input Level : Center)


Residual Noise Level

Line Output : -103 dBu (Input Sens : +4 dBu, Input Level : Minimum)


Frequency Response

20Hz – 40kHz(0/-3 dB)


Dynamic Range

AD : 100 dB


Phantom Power

48 V + or – 4 V, 8 mA per 1 channel (20 mA or less in all channels)


OTHER TERMINALS

USB Port

Mini-B Type Connecter


Control Sync Jack

Stereo Mini Type Jack


OTHERS

Display

128 x 64 dot organic LED


Power Supply

AC adaptor (PSB-1U), AA type battery x 4 (Alkaline or NiMH)


Current Draw

1.2 A


SYSTEM REQUIREMENTS

Microsoft® Windows® Vista®/XP/2000, Mac OS X 10.2 or later


SIZE AND WEIGHT

Width

157 mm
6-3/16 inches


Depth

183 mm
7-1/4 inches


Height

61 mm
2-7/16 inches


Weight

1.3 kg including batteries
2 lbs. 14 oz including batteries
