CUBE Lite

Combining great COSM guitar tones, iOS interfacing, and a quality 2.1 Channel audio system, the CUBE Lite Guitar Amplifier lets you play and record at home along with your iPhone, iPad, or iPod touch. Connect your iOS device to the i-CUBE LINK jack and launch the free CUBE JAM app, then riff along with backing tracks and record your playing to share your music and archive song ideas. With stereo speakers and an integrated subwoofer, you’ll enjoy rich, satisfying sound reproduction for both guitar playing and casual music listening. And with an attractive look that blends with any home décor, the CUBE Lite Guitar Amplifier can occupy a permanent spot in your living space, always at the ready when you want to plug in and jam.

Description

FEATURE

  • Compact guitar amp with a stylish look for home living spaces
  • JC CLEAN, CRUNCH, and EXTREME COSM tones, plus stereo chorus and reverb effects
  • Great-sounding 2.1 Channel audio system, with stereo speakers and integrated subwoofer
  • i-CUBE LINK jack provides simple audio interfacing with Apple’s iPhone, iPad, and iPod touch
  • Free CUBE JAM app for iOS plays songs and minus-one jam tracks, and lets you record the CUBE Lite’s COSM amp tones along with music playback
  • Includes cable for two-way communication (playback and recording) with iOS devices
  • Available in three colors: black, white, or red

Killer Guitar Tones

The CUBE Lite Guitar Amplifier provides three great COSM tones—JC CLEAN, CRUNCH, and EXTREME—giving you a wide range of sounds for playing any style of music. Reverb and chorus effects are onboard as well, with true stereo performance for a wide, expansive sound.

Easy iOS Device Integration with i-CUBE LINK

With the newly developed i-CUBE LINK interface, the CUBE Lite Guitar Amplifier lets you integrate your iPhone, iPad, or iPod touch with your axe in a familiar and satisfying way—through a real amp with great tone. Other interfaces require bulky, specialized add-ons to plug your guitar direct into the iOS device, resulting in a clumsy, inconvenient playing experience. With i-CUBE LINK, you just connect to your device’s audio jack with the included cable, then blend the COSM tones and iOS audio together at the amp with simple, intuitive controls. The versatile i-CUBE LINK jack can also be used as a simple stereo input, enabling you to hook up nearly any music player or audio device and play it through the CUBE Lite.

Direct Mode

Normally, recording from the CUBE Lite Guitar Amplifier into CUBE JAM or another app captures the sound as you hear it, with the COSM tone applied. Activating the CUBE Lite’s Direct Mode feature lets you capture dry guitar sounds while monitoring with the COSM sound. Recording dry tracks in this way gives you the option to experiment later by “re-amping” with any guitar app of your choice. Direct Mode also allows you to use real-time guitar processing in any app, monitoring the live output with the CUBE Lite.

2.1 Channel Audio System for Impressive Sound

Equipped with stereo speakers and an integrated subwoofer, the CUBE Lite’s powerful 2.1 Channel audio system delivers a rich, full sound that belies the amp’s compact footprint. When you want to practice silently, just plug in a set of headphones to mute the onboard speakers.

CUBE JAM App

The free Roland CUBE JAM app turns your iOS device into a fun command center for jamming, recording, and learning. Play back commercial songs and minus-one tracks through the CUBE Lite via i-CUBE LINK, and riff along for hours with awesome COSM tones. CUBE JAM also records audio through the i-CUBE LINK connection, allowing you to easily capture your jams. After you’re done recording, you can adjust the volume of your guitar and backing music independently, then export your mix to a 16-bit, 44.1 kHz WAV file. The app also includes great tools for music practice, including independent speed and pitch adjustment of audio playback, Center Cancel to remove solos and create your own jam tracks, and more.

Stylish Design for Modern Living Spaces

Offering an appearance more like a consumer audio system than a typical rugged-look guitar amp, the CUBE Lite blends in seamlessly with any home living space. In addition to being a great guitar amp, it also doubles as a high-quality playback system for your digital music library. With three different finishes to choose from (black, white, or red), you’re sure to find the perfect match for your home furnishings.

CUBE Lite

                  Rated Power Output

                  10 W (Stereo speakers 3 W x 2 + Subwoofer 4 W)


                  Nominal Input Level (1 kHz)

                  INPUT: -10 dBu
                  i-CUBE LINK/STEREO AUX IN: -10 dBu


                  Speakers

                  7.5 cm (3 inches) x 3


                  Amp Types

                  JC CLEAN
                  CRUNCH
                  EXTREME


                  Controls

                  POWER switch
                  Amp Type switch
                  DRIVE knob
                  VOLUME knob
                  BASS knob
                  TREBLE knob
                  CHORUS/REVERB knob


                  Control (i-CUBE LINK/STEREO AUX IN)

                  VOLUME knob


                  Indicators

                  Amp Type


                  Connectors

                  INPUT jack: 1/4-inch phone type
                  i-CUBE LINK/STEREO AUX IN jack: 4-pole miniature phone type
                  PHONES jack: Stereo miniature phone type
                  DC IN jack


                  Power Supply

                  AC adaptor (DC 5.7 V)


                  Current Draw

                  1000 mA


                  Accessories

                  Owner’s Manual
                  AC adaptor
                  Mini cable (4 poles)


                  SIZE AND WEIGHT (EXCLUDING AC ADAPTOR)

                  Width

                  250 mm
                  9-7/8 inches


                  Depth

                  147 mm
                  5-13/16 inches


                  Height

                  135 mm
                  5-6/16 inches


                  Weight

                  1.7 kg
                  3 lbs. 12 oz.
